Specifications
- Terminal Pozisyonu
- DUAL
- Number Of Macro Cells
- 10
- Terminal Adımı
- 2.54mm
- Number Of Dedicated Inputs
- 11
- Kurşunsuz
- Lead Free
- Parça Durumu
- Obsolete
- Ambalaj
- Bulk
- Besleme Gerilimi
- 5V
- Max Supply Voltage
- 5.25V
- Min Supply Voltage
- 4.75V
- Nominal Supply Current
- 130mA
- Number Of Outputs
- 10
- Terminal Sayısı
- 24
- Montaj
- Through Hole
- Tepe Reflow Süresi (maks. sn)
- 30
- Tepe Reflow Sıcaklığı (°C)
- 225
- Çalışma Sıcaklığı
- 0°C~75°C TA
- Power Supplies
- 5V
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 1996
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Temel Parça No
- GAL22V10
- Maks. Oturma Yüksekliği
- 5.334mm
- Number Of Product Terms
- 132
- Frekans
- 125MHz
- Number Of Ios
- 10
- HTS Kodu
- 8542.39.00.01
- Output Function
- MACROCELL
- Kurşunsuz Kodu
- no
- Voltage Supply Internal
- 4.75V~5.25V
- JESD-609 Kodu
- e0
- Kılıf / Paket
- 24-DIP (0.300, 7.62mm)
- Architecture
- PAL-TYPE
- Operating Supply Voltage
- 5V
- Propagation Delay
- 10 ns
- Genişlik
- 7.62mm
- Pin Sayısı
- 24
- Seri
- GAL®22V10
- Uzunluk
- 31.75mm
- ECCN Kodu
- EAR99
