Specifications
- Forward Current
- 20mA
- Shape
- CYLINDRICAL
- Tcode
- T-1
- Akım
- 25mA Green 30mA Red
- Montaj
- Through Hole
- Forward Voltage
- 2.2V
- Millicandela Rating
- 12mcd Green, 8mcd Red
- Kurşunsuz Kodu
- yes
- Operating Temperature Max
- 85°C
- Operating Temperature Min
- -40°C
- Lens Size
- 3.00mm Dia
- RoHS Durumu
- ROHS3 Compliant
- Terminal Adımı
- 1.9mm
- Additional Feature
- UL RECOGNIZED, IC COMPATIBLE, HIGH RELIABILITY
- Optoelectronic Device Type
- DUAL COLOR LED
- Ambalaj
- Bulk
- Wavelength Peak
- 565nm 627nm
- Kılıf / Paket
- 100
- Lens Style
- Round with Flat Top
- Parça Durumu
- Active
- Terminal Sayısı
- 3
- Kurşunsuz
- Lead Free
- Viewing Angle
- 100°
- Montaj Tipi
- Through Hole, Right Angle
- Configuration
- Single
- HTS Kodu
- 8541.40.20.00
- ECCN Kodu
- EAR99
- Renk
- Green, Red
- Yayın Yılı
- 2011
- Lens Type
- Diffused, White
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Luminous Intensity
- 20 mcd
- Fonksiyon Sayısı
- 1
- Nominal Gerilim
- 2.2V Green 2V Red
- Illumination Color
- Green, Red
- Fabrika Tedarik Süresi
- 12 Weeks
- Overall Height
- 7.11mm
