Volume pricing
- 1+ pcs$1.27
- 10+ pcs$1.20
- 100+ pcs$1.13
- 500+ pcs$1.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Connector Support Type
- CONNECTOR ACCESSORY
- Terminal Type
- PC Pin
- Contact Materials
- Brass
- Uzunluk
- 13.081mm
- Length Below Flange
- 0.265 6.73mm
- Material Insulation
- Polytetrafluoroethylene (PTFE)
- Flange Diameter
- 0.125 (3.18mm)
- Mounting Hole Diameter
- 0.086 (2.18mm)
- Fabrika Tedarik Süresi
- 6 Weeks
- Insulation Color
- White
- Pin Size Below Flange
- 0.040 1.02mm Dia
- Pin Size Above Flange
- 0.040 1.02mm Dia
- Terminal
- Press-Fit
- Hole Diameter
- 2.1844 mm
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Insulation
- Insulated
- Board Thickness
- 0.062 1.57mm
- Montaj
- Through Hole
- Length Above Flange
- 0.210 5.33mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Terminal Style
- Double End
- Yayın Yılı
- 2007
- Parça Durumu
- Active
- Length Overall
- 0.515 13.08mm
- Contact Finish
- Tin
