Specifications
- Montaj
- Surface Mount
- Uzunluk
- 7mm
- Montaj Tipi
- Surface Mount, Right Angle
- Style
- Board to Cable/Wire
- Orientation
- Right Angle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Ac
- 50V
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -25°C~85°C
- Option
- GENERAL PURPOSE
- Insulation Materials
- Polyamide (PA), Nylon
- Mixed Contacts
- NO
- Voltage Rated Ac
- 50V
- Max Current Rating
- 1A
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 16 Weeks
- Reach Svhc
- No SVHC
- Housing Material
- Polyamide
- Contact Shape
- Square
- JESD-609 Kodu
- e2
- Iec Conformance
- NO
- Akım Değeri
- 1A
- Insulation Color
- Natural
- Depth
- 4.95mm
- Ul Flammability Code
- 94V-0
- Contact Materials
- Copper Alloy
- Özellikler
- Solder Retention
- Insulation Resistance
- 100MOhm
- RoHS Durumu
- RoHS Compliant
- Pitch Mating
- 0.039 1.00mm
- Terminal
- Solder
- Sıra Sayısı
- 1
- Yayın Yılı
- 2005
- Pozisyon Sayısı
- 5
- Contact Finish Mating
- Tin
- Contact Resistance
- 40mOhm
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Lead Free
- Gender
- Male
- Din Conformance
- NO
