Specifications
- Yükseklik
- 2.9mm
- Mixed Contacts
- NO
- Insulation Materials
- Polyamide (PA), Nylon
- Option
- GENERAL PURPOSE
- Fabrika Tedarik Süresi
- 16 Weeks
- Housing Material
- Nylon
- Max Current Rating
- 1A
- ECCN Kodu
- EAR99
- Montaj
- Surface Mount
- Uzunluk
- 6mm
- Montaj Tipi
- Surface Mount, Right Angle
- Max Voltage Rating Ac
- 50V
- Genişlik
- 4.25mm
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -25°C~85°C
- Style
- Board to Cable/Wire
- Orientation
- Right Angle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Terminal
- Solder
- Pitch Mating
- 0.039 1.00mm
- JESD-609 Kodu
- e2
- Akım Değeri
- 1A
- Iec Conformance
- NO
- Depth
- 4.95mm
- Contact Shape
- Square
- Contact Materials
- Copper Alloy
- Özellikler
- Solder Retention
- Max Voltage Rating Dc
- 50V
- Insulation Height
- 0.114 2.90mm
- Shrouding
- Shrouded - 4 Wall
- Seri
- SR
- Additional Feature
- SIDE ENTRY
- Filter Feature
- NO
- Pozisyon Sayısı
- 4
- Contact Finish Mating
- Tin
- Sıra Sayısı
- 1
- Yayın Yılı
- 2010
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Push-Pull
