Specifications
- Insulation Color
- Natural
- Terminal
- Press-Fit, Solder
- Genişlik
- 6.35mm
- Contact Materials
- Brass
- Additional Feature
- SHROUDED, SIDE ENTRY
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- HTS Kodu
- 8536.69.40.40
- Contact Resistance
- 10mOhm
- Style
- Board to Cable/Wire
- Kurşunsuz Kodu
- yes
- Weight
- 28.349523g
- Option
- GENERAL PURPOSE
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2010
- Contact Length Post
- 0.134 3.40mm
- Contact Shape
- Square
- Voltage Rated Ac
- 250V
- Akım Değeri
- 3A
- Wirecable Gauge
- 22 AWG
- Uzunluk
- 25.4mm
- Contact Type
- Male Pin
- Contact Finish Mating
- Tin
- REACH Uyumluluk Kodu
- unknown
- Gender
- Male
- Montaj Tipi
- Through Hole, Right Angle
- Ambalaj
- Bulk
- Ul Flammability Code
- 94V-0
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Montaj
- Through Hole
- Number Of Positions Loaded
- All
- Parça Durumu
- Active
- Seri
- XH
- Mixed Contacts
- NO
- Kurşunsuz
- Lead Free
- Lead Pitch
- 2.5mm
- Material Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 7
- Sıra Sayısı
- 1
- Connector Type
- Header
