Volume pricing
- 1+ pcs$0.10
- 10+ pcs$0.10
- 100+ pcs$0.09
- 500+ pcs$0.09
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fastening Type
- Detent Lock
- Contact Finish Mating
- Tin
- Contact Type
- Male Pin
- JESD-609 Kodu
- e3
- Iec Conformance
- NO
- Nominal Gerilim
- 250V
- Pitch Mating
- 0.098 2.50mm
- Insulation Height
- 0.240 6.10mm
- Filter Feature
- NO
- Contact Shape
- Square
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Length Post
- 0.134 3.40mm
- Mil Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 20 Weeks
- Terminal Adımı
- 2.5mm
- Number Of Positions Loaded
- All
- Din Conformance
- NO
- Ul Flammability Code
- 94V-0
- Shrouding
- Shrouded - 4 Wall
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Additional Feature
- SHROUDED, SIDE ENTRY
- Contact Materials
- Brass
- Terminal
- Press-Fit, Solder
- Insulation Color
- Natural
- Montaj Tipi
- Through Hole, Right Angle
- Ambalaj
- Bulk
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 7
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Option
- GENERAL PURPOSE
- Style
- Board to Cable/Wire
- Mixed Contacts
- NO
- Current Rating Amps
- 3A
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Seri
- XH
