Volume pricing
- 1+ pcs$0.39
- 10+ pcs$0.36
- 100+ pcs$0.34
- 500+ pcs$0.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Connector Type
- Header
- Option
- GENERAL PURPOSE
- Nominal Gerilim
- 100V
- Housing Color
- Natural
- Kurşunsuz Kodu
- yes
- Din Conformance
- NO
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 1
- Fastening Type
- Detent Lock
- Seri
- PH
- Additional Feature
- SIDE ENTRY
- Housing Material
- Nylon
- Filter Feature
- NO
- Insulation Height
- 0.189 4.80mm
- Kurşunsuz
- Lead Free
- Ul Flammability Code
- 94V-0
- Iec Conformance
- NO
- Montaj Tipi
- Through Hole, Right Angle
- Current Rating Amps
- 2A
- JESD-609 Kodu
- e3
- Mixed Contacts
- NO
- Pozisyon Sayısı
- 16
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 20 Weeks
- Contact Type
- Male Pin
- Montaj
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch Mating
- 0.079 2.00mm
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Finish Mating
- Tin
- Yayın Yılı
- 2008
- Parça Durumu
- Active
- Contact Materials
- Brass
- Terminal
- Press-Fit, Solder
- Contact Shape
- Square
- HTS Kodu
- 8536.69.40.40
- ECCN Kodu
- EAR99
- Shrouding
- Shrouded - 4 Wall
- Mil Conformance
- NO
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
