Specifications
- Insulation Color
- Natural
- HTS Kodu
- 8536.69.40.40
- Montaj
- Surface Mount
- Seri
- ZH
- Insulation Materials
- Polyamide (PA6T), Nylon 6T
- Mil Conformance
- NO
- Uzunluk
- 21mm
- Pitch Mating
- 0.059 1.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- LOW PROFILE
- Contact Materials
- Brass
- Parça Durumu
- Active
- Yayın Yılı
- 2005
- Orientation
- Right Angle
- Contact Shape
- Circular
- Akım Değeri
- 1A
- Çalışma Sıcaklığı
- -25°C~85°C
- Din Conformance
- NO
- JESD-609 Kodu
- e3
- Mixed Contacts
- NO
- Montaj Tipi
- Surface Mount, Right Angle
- Connector Type
- Header
- Özellikler
- Solder Retention
- Material Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 12
- Contact Resistance
- 30mOhm
- Housing Material
- Polyamide
- Fabrika Tedarik Süresi
- 12 Weeks
- Shrouding
- Shrouded - 4 Wall
- Gender
- Male
- Insulation Height
- 0.146 3.70mm
- Kurşunsuz
- Lead Free
- Ambalaj
- Tape & Reel (TR)
- Sıra Sayısı
- 1
- Style
- Board to Cable/Wire
- Iec Conformance
- NO
- Fastening Type
- Detent Lock
- Max Voltage Rating Ac
- 50V
- Max Current Rating
- 1A
- Number Of Positions Loaded
- All
