Specifications
- Additional Feature
- SIDE ENTRY
- Contact Materials
- Brass
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 1997
- Parça Durumu
- Active
- Uzunluk
- 25.9mm
- Pitch Mating
- 0.079 2.00mm
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Mil Conformance
- NO
- Seri
- PH
- Montaj
- Through Hole
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Header
- Nominal Gerilim
- 100V
- Montaj Tipi
- Through Hole, Right Angle
- Mixed Contacts
- NO
- Din Conformance
- NO
- JESD-609 Kodu
- e3
- Akım Değeri
- 2A
- Contact Shape
- Square
- Çalışma Sıcaklığı
- -25°C~85°C
- Style
- Board to Cable/Wire
- Ambalaj
- Bulk
- Sıra Sayısı
- 1
- Fastening Type
- Detent Lock
- Iec Conformance
- NO
- Yükseklik
- 9.4mm
- Kurşunsuz
- Lead Free
- Insulation Height
- 0.189 4.80mm
- Gender
- Male
- Genişlik
- 4.5mm
- Contact Length Post
- 0.134 3.40mm
- Material Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 12
- Housing Material
- Nylon
- Shrouding
- Shrouded - 4 Wall
- Fabrika Tedarik Süresi
- 19 Weeks
- Terminal
- Press-Fit, Solder
- ECCN Kodu
- EAR99
- Contact Finish Mating
- Tin
