Specifications
- Mil Conformance
- NO
- Gender
- Male
- Insulation Height
- 0.189 4.80mm
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Current Rating Amps
- 2A
- Fabrika Tedarik Süresi
- 18 Weeks
- Shrouding
- Shrouded - 4 Wall
- Housing Material
- Nylon
- Pozisyon Sayısı
- 11
- Material Flammability Rating
- UL94 V-0
- Seri
- PH
- Montaj
- Through Hole
- HTS Kodu
- 8536.69.40.40
- Contact Length Post
- 0.134 3.40mm
- Parça Durumu
- Active
- Iec Conformance
- NO
- Yayın Yılı
- 2002
- Fastening Type
- Detent Lock
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Style
- Board to Cable/Wire
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Contact Materials
- Brass
- Additional Feature
- SIDE ENTRY
- Pitch Mating
- 0.079 2.00mm
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Lengthmating
- 0.130 3.30mm
- Contact Shape
- Square
- Housing Color
- Natural
- Number Of Positions Loaded
- All
- Contact Type
- Male Pin
- Nominal Gerilim
- 100V
- Filter Feature
- NO
- Contact Finish Mating
- Tin
- Connector Type
- Header
- ECCN Kodu
- EAR99
- Terminal
- Press-Fit, Solder
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- RoHS Compliant
