Specifications
- Contact Finish Mating
- Tin
- Özellikler
- Board Guide
- Terminal Adımı
- 2mm
- Contact Type
- Male Pin
- Nominal Gerilim
- 250V
- Filter Feature
- NO
- Terminal
- Kinked Pin, Solder
- Connector Type
- Header
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- RoHS Compliant
- Ul Flammability Code
- 94V-0
- Montaj Tipi
- Through Hole, Right Angle
- JESD-609 Kodu
- e3
- Din Conformance
- NO
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Contact Lengthmating
- 0.126 3.20mm
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Shape
- Square
- Housing Color
- White
- Number Of Positions Loaded
- All
- Fastening Type
- Locking Ramp
- Yayın Yılı
- 2005
- Iec Conformance
- NO
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Contact Materials
- Copper Alloy
- Style
- Board to Cable/Wire
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz
- Lead Free
- Pitch Mating
- 0.079 2.00mm
- Mil Conformance
- NO
- Insulation Height
- 0.256 6.50mm
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Shrouding
- Shrouded - 4 Wall
- Current Rating Amps
- 3A
- Fabrika Tedarik Süresi
- 16 Weeks
- Seri
- PA
- Montaj
- Through Hole
