Volume pricing
- 1+ pcs$0.19
- 10+ pcs$0.18
- 100+ pcs$0.17
- 500+ pcs$0.16
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Din Conformance
- NO
- Kurşunsuz
- Contains Lead
- Overall Contact Length
- 0.256 6.50mm
- RoHS Durumu
- Non-RoHS Compliant
- Contact Finish Mating
- Tin-Lead
- Filter Feature
- NO
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Test Voltage
- 500V
- Number Of Positions Loaded
- All
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Press-Fit, Solder
- Sıra Sayısı
- 1
- Contact Lengthmating
- 0.094 2.40mm
- Pozisyon Sayısı
- 8
- Gender
- Male
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Nylon
- Additional Feature
- TOP ENTRY
- Insulation Height
- 0.177 4.50mm
- Lead Pitch
- 1.5mm
- Ul Flammability Code
- 94V-0
- Contact Shape
- Circular
- ECCN Kodu
- EAR99
- Insulation Color
- Natural
- Seri
- ZH
- Çalışma Sıcaklığı
- -25°C~85°C
- Montaj
- Through Hole
- Kurşunsuz Kodu
- no
- Mil Conformance
- NO
- Orientation
- Vertical
- Contact Materials
- Brass
- Contact Length Post
- 0.106 2.69mm
- Style
- Board to Cable/Wire
- Pitch Mating
- 0.059 1.50mm
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Connector Type
- Header
- Akım Değeri
- 1A
- Stack Height Mating
- 5.6mm
