Volume pricing
- 1+ pcs$0.08
- 10+ pcs$0.08
- 100+ pcs$0.07
- 500+ pcs$0.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mixed Contacts
- NO
- RoHS Durumu
- RoHS Compliant
- Seri
- EH
- Nominal Gerilim
- 250V
- Contact Lengthmating
- 0.130 3.30mm
- Insulation Height
- 0.236 6.00mm
- Pozisyon Sayısı
- 7
- Uzunluk
- 20mm
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Nylon
- Ul Flammability Code
- 94V-0
- Mil Conformance
- NO
- Contact Length Post
- 0.126 3.20mm
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Iec Conformance
- NO
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Contact Materials
- Brass
- Insulation Color
- Natural
- Connector Type
- Header
- Orientation
- Straight
- Contact Type
- Male Pin
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Çalışma Sıcaklığı
- -25°C~85°C
- Number Of Positions Loaded
- All
- Housing Color
- White
- Gender
- Male
- Shrouding
- Shrouded - 3 Wall
- Yükseklik
- 6mm
- Reach Svhc
- Unknown
- Additional Feature
- POLARIZED, TOP ENTRY, SHROUDED
- Terminal
- Press-Fit, Solder
- Pitch Mating
- 0.098 2.50mm
- JESD-609 Kodu
- e3
- Fabrika Tedarik Süresi
- 16 Weeks
- Style
- Board to Cable/Wire
