Specifications
- Parça Durumu
- Active
- Contact Resistance
- 20mOhm
- RoHS Durumu
- RoHS Compliant
- Orientation
- Right Angle
- Contact Lengthmating
- 0.303 7.70mm
- Pozisyon Sayısı
- 6
- Housing Material
- Polyamide
- Pitch Mating
- 0.156 3.96mm
- Yayın Yılı
- 2005
- Connector Type
- Header
- Gender
- Male
- Housing Color
- White
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- VH
- Style
- Board to Cable/Wire
- Contact Length Post
- 0.142 3.60mm
- Contact Type
- Male Pin
- Insulation Color
- Natural
- Kurşunsuz
- Lead Free
- Din Conformance
- NO
- Sıra Sayısı
- 1
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 16 Weeks
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -25°C~85°C
- Option
- GENERAL PURPOSE
- Fastening Type
- Locking Ramp
- Shrouding
- Shrouded - 1 Wall
- Mixed Contacts
- NO
- Contact Finish Mating
- Tin
- Uzunluk
- 23.7mm
- Contact Shape
- Square
- Filter Feature
- NO
- Lead Pitch
- 3.96mm
- Ul Flammability Code
- 94V-0
- REACH Uyumluluk Kodu
- unknown
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Akım Değeri
- 10A
- ECCN Kodu
- EAR99
