Specifications
- Housing Material
- Nylon
- Pozisyon Sayısı
- 6
- Pitch Mating
- 0.098 2.50mm
- Stack Height Mating
- 9.8mm
- Yayın Yılı
- 2010
- Contact Resistance
- 10mOhm
- Contact Plating
- Lead, Tin
- Parça Durumu
- Obsolete
- RoHS Durumu
- Non-RoHS Compliant
- Orientation
- Straight
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Kurşunsuz
- Contains Lead
- Din Conformance
- NO
- Terminal
- Press-Fit, Solder
- Sıra Sayısı
- 1
- Nominal Gerilim
- 250V
- Connector Type
- Header
- Insulation Resistance
- 1GOhm
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- XH
- Style
- Board to Cable/Wire
- Insulation Color
- Natural
- Contact Length Post
- 0.134 3.40mm
- Contact Type
- Male Pin
- Contact Finish Mating
- Tin-Lead
- Contact Shape
- Square
- Filter Feature
- NO
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -25°C~85°C
- Option
- GENERAL PURPOSE
- Fastening Type
- Detent Lock
- Shrouding
- Shrouded - 4 Wall
- Mixed Contacts
- NO
- Yükseklik
- 7mm
- Terminal Adımı
- 2.5mm
- Montaj Tipi
- Through Hole
- Mil Conformance
- NO
- Montaj
- Through Hole
- Insulation Height
- 0.276 7.00mm
