B6B-PH-SM4-TBT(LF)(SN)

Specifications

Fastening Type

Detent Lock

Shrouding

Shrouded - 4 Wall

RoHS Durumu

RoHS Compliant

Mixed Contacts

NO

Material Flammability Rating

UL94 V-0

Çalışma Sıcaklığı

-25°C~85°C

Parça Durumu

Active

Option

GENERAL PURPOSE

Pozisyon Sayısı

6

Filter Feature

NO

Pitch Mating

0.079 2.00mm

Özellikler

Pick and Place, Solder Retention

Stack Height Mating

8.6mm

Current Rating Amps

2A

Yayın Yılı

2008

Contact Finish Mating

Tin

Contact Lengthmating

0.130 3.30mm

Contact Shape

Square

Number Of Positions Loaded

All

Nem Hassasiyeti (MSL)

1 (Unlimited)

Insulation Materials

Polyamide (PA6T), Nylon 6T

Iec Conformance

NO

Seri

PH

Style

Board to Cable/Wire

Insulation Color

Natural

Contact Type

Male Pin

JESD-609 Kodu

e3

Total Number Of Contacts

6

Connector Type

Header

Ambalaj

Tape & Reel (TR)

Ul Flammability Code

94V-0

Din Conformance

NO

Fabrika Tedarik Süresi

18 Weeks

Terminal

Solder

Insulation Height

0.260 6.60mm

Montaj

Surface Mount

Sıra Sayısı

1

Additional Feature

LOW PROFILE

Nominal Gerilim

100V

Contact Materials

Copper Alloy
