Specifications
- Montaj Tipi
- Through Hole
- Mil Conformance
- NO
- Montaj
- Through Hole
- Insulation Height
- 0.236 6.00mm
- Additional Feature
- TOP ENTRY
- Contact Materials
- Brass
- Kurşunsuz Kodu
- no
- Lead Pitch
- 2mm
- REACH Uyumluluk Kodu
- unknown
- Number Of Positions Loaded
- All
- ECCN Kodu
- EAR99
- Akım Değeri
- 2A
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Iec Conformance
- NO
- Pin Sayısı
- 4
- JESD-609 Kodu
- e3
- Contact Finish Mating
- Tin-Lead
- Contact Shape
- Square
- Filter Feature
- NO
- Test Voltage
- 800V
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -25°C~85°C
- Option
- GENERAL PURPOSE
- Fastening Type
- Detent Lock
- Shrouding
- Shrouded - 4 Wall
- Mixed Contacts
- NO
- Kurşunsuz
- Contains Lead
- Din Conformance
- NO
- Terminal
- Press-Fit, Solder
- Sıra Sayısı
- 1
- Nominal Gerilim
- 100V
- Connector Type
- Header
- Overall Contact Length
- 0.333 8.45mm
- Insulation Resistance
- 1GOhm
- Ambalaj
- Bulk
- Gender
- Male
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- PH
- Style
- Board to Cable/Wire
- Insulation Color
- Natural
