Specifications
- Mixed Contacts
- NO
- Terminal
- Solder
- Yayın Yılı
- 2003
- Seri
- VH
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e3
- Contact Materials
- Brass
- Fastening Type
- Locking Ramp
- Contact Finish Mating
- Tin-Lead
- Contact Plating
- Lead, Tin
- Contact Lengthmating
- 0.303 7.70mm
- Style
- Board to Cable/Wire
- Parça Durumu
- Obsolete
- Din Conformance
- NO
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Housing Material
- Nylon
- Connector Type
- Header
- Montaj Tipi
- Through Hole, Right Angle
- Additional Feature
- SIDE ENTRY
- Contact Shape
- Square
- Gender
- Male
- Contact Type
- Male Pin
- HTS Kodu
- 8536.69.40.40
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Kurşunsuz
- Contains Lead
- Insulation Height
- 0.335 8.51mm
- Number Of Positions Loaded
- All
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Pitch Mating
- 0.156 3.96mm
- Contact Length Post
- 0.142 3.60mm
- Filter Feature
- NO
- Lead Pitch
- 3.96mm
- RoHS Durumu
- Non-RoHS Compliant
- Current Rating Amps
- 10A
- Pozisyon Sayısı
- 2
- Ambalaj
- Bulk
- Nominal Gerilim
- 250V
