Specifications
- Din Conformance
- NO
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Stack Height Mating
- 13.8mm
- Mixed Contacts
- NO
- Additional Feature
- TOP ENTRY, SHROUDED, POLARIZED
- Pitch Mating
- 0.098 2.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 3A
- Filter Feature
- NO
- Material Flammability Rating
- UL94 V-0
- Ul Flammability Code
- 94V-0
- Yayın Yılı
- 2005
- Orientation
- Straight
- Contact Finish Mating
- Tin
- Contact Length Post
- 0.138 3.50mm
- Terminal
- Solder
- Montaj
- Through Hole
- Parça Durumu
- Active
- Insulation Materials
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Row Spacing Mating
- 0.098 (2.50mm)
- Çalışma Sıcaklığı
- -25°C~85°C
- Pozisyon Sayısı
- 20
- Connector Type
- Header
- RoHS Durumu
- RoHS Compliant
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Number Of Positions Loaded
- All
- Contact Materials
- Copper Alloy
- Seri
- XAD
- Contact Type
- Male Pin
- Style
- Board to Cable/Wire
- Insulation Color
- Natural
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 16 Weeks
- Nominal Gerilim
- 250V
- Mil Conformance
- NO
- Contact Shape
- Circular
