Specifications
- Row Spacing Mating
- 0.098 (2.50mm)
- Kurşunsuz Kodu
- yes
- Contact Type
- Male Pin
- Contact Shape
- Circular
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Header
- Montaj Tipi
- Through Hole
- Mixed Contacts
- NO
- Fabrika Tedarik Süresi
- 16 Weeks
- Kurşunsuz
- Lead Free
- Shrouding
- Shrouded - 4 Wall
- Insulation Materials
- Polyamide (PA66), Nylon 6/6, Glass Filled
- Akım Değeri
- 3A
- Fastening Type
- Locking Ramp
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Option
- GENERAL PURPOSE
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -25°C~85°C
- Mil Conformance
- NO
- Yayın Yılı
- 2005
- Iec Conformance
- NO
- Orientation
- Straight
- Contact Length Post
- 0.138 3.50mm
- Sıra Sayısı
- 2
- Nominal Gerilim
- 250V
- Additional Feature
- TOP ENTRY, SHROUDED, POLARIZED
- Contact Finish Mating
- Tin
- RoHS Durumu
- RoHS Compliant
- Insulation Color
- Natural
- Seri
- XAD
- Style
- Board to Cable/Wire
- Pozisyon Sayısı
- 10
- Filter Feature
- NO
- Din Conformance
- NO
- Terminal
- Solder
- Insulation Height
- 0.398 10.11mm
- HTS Kodu
- 8536.69.40.40
