Specifications
- Genişlik
- 5.3mm
- Ambalaj
- Bulk
- Montaj Tipi
- Through Hole
- Contact Length Post
- 0.118 3.00mm
- Insulation Height
- 0.303 7.70mm
- Shrouding
- Shrouded - 4 Wall
- Nominal Gerilim
- 250V
- Mil Conformance
- NO
- Style
- Board to Cable/Wire
- Additional Feature
- SHROUDED, TOP ENTRY
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Yayın Yılı
- 2005
- Kurşunsuz Kodu
- yes
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Material Flammability Rating
- UL94 V-0
- Contact Lengthmating
- 0.126 3.20mm
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Montaj
- Through Hole
- Uzunluk
- 18mm
- Iec Conformance
- NO
- Çalışma Sıcaklığı
- -25°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Locking Ramp
- Current Rating Amps
- 3A
- Housing Material
- Nylon
- Pitch Mating
- 0.079 2.00mm
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 16 Weeks
- Sıra Sayısı
- 1
- Parça Durumu
- Active
- Contact Materials
- Copper Alloy
- Seri
- PA
- Contact Finish Mating
- Tin
- Housing Color
- White
- Yükseklik
- 7.7mm
- Terminal Adımı
- 2mm
- Connector Type
- Header
- ECCN Kodu
- EAR99
