Specifications
- Lead Pitch
- 6.2mm
- Depth
- 14.2mm
- Contact Resistance
- 10mOhm
- Terminal
- Solder
- Voltage Rated Ac
- 600V
- Filter Feature
- NO
- Shell Material
- POLYAMIDE66
- Din Conformance
- NO
- Empty Shell
- NO
- Insulation Color
- Natural
- Contact Type
- Male Pin
- JESD-609 Kodu
- e3
- Stack Height Mating
- 29.2mm
- Number Of Positions Loaded
- All
- Gender
- Male
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 18 Weeks
- Contact Current Rating
- 20A
- Housing Material
- Nylon
- Reach Svhc
- No SVHC
- Pitch Mating
- 0.244 6.20mm
- Connector Type
- Header
- Contact Shape
- Square
- ECCN Kodu
- EAR99
- Seri
- VL
- Contact Finish Mating
- Tin
- Orientation
- Straight
- Housing Color
- White
- Sıra Sayısı
- 1
- Parça Durumu
- Active
- Contact Materials
- Copper Alloy
- Yükseklik
- 16.4mm
- RoHS Durumu
- RoHS Compliant
- Montaj
- Through Hole
- Kurşunsuz
- Lead Free
- Uzunluk
- 19.6mm
- Max Voltage Rating Ac
- 600V
- Pozisyon Sayısı
- 3
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
