Volume pricing
- 1+ pcs$7.39
- 10+ pcs$6.97
- 100+ pcs$6.57
- 500+ pcs$6.20
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Phases
- 3
- Voltage Forward Vf Max If
- 1.04V @ 15A
- Case Connection
- ISOLATED
- JESD-609 Kodu
- e4
- Max Reverse Leakage Current
- 300μA
- Terminal Pozisyonu
- UPPER
- Genişlik
- 28.5mm
- Kılıf / Paket
- 5-Square, FO-B
- Forward Voltage
- 1.7V
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Peak Nonrepetitive Surge Current
- 600A
- Yükseklik
- 10mm
- Terminal Kaplaması
- Gold (Au) - with Nickel (Ni) barrier
- Montaj Tipi
- QC Terminal
- Diode Element Material
- SILICON
- Configuration
- BRIDGE, 6 ELEMENTS
- Temel Parça No
- VUO36
- Current Reverse Leakage Vr
- 40μA @ 800V
- Average Rectified Current
- 27A
- Pin Sayısı
- 5
- Number Of Elements
- 1
- Diode Type
- Three Phase
- Terminal Formu
- SOLDER LUG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 28.5mm
- Terminal Sayısı
- 5
- Max Surge Current
- 550A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Max Repetitive Reverse Voltage Vrrm
- 800V
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Peak Reverse Current
- 40μA
- Parça Durumu
- Active
- Montaj
- Chassis Mount, Screw
- Ambalaj
- Bulk
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2012
- Fabrika Tedarik Süresi
- 16 Weeks
- Kurşunsuz Kodu
- yes
- Additional Feature
- UL RECOGNIZED
