Specifications
- Pin Sayısı
- 5
- Configuration
- BRIDGE, 6 ELEMENTS
- Temel Parça No
- VUO35
- Current Reverse Leakage Vr
- 40μA @ 1800V
- Montaj Tipi
- Chassis Mount
- Diode Element Material
- SILICON
- Peak Nonrepetitive Surge Current
- 440A
- Yükseklik
- 22mm
- Diode Type
- Three Phase
- Number Of Elements
- 1
- Voltage Peak Reverse Max
- 1.8kV
- Max Reverse Leakage Current
- 300μA
- Voltage Forward Vf Max If
- 1.1V @ 15A
- Case Connection
- ISOLATED
- Current Average Rectified Io
- 38A
- Pin Sayısı
- 5
- Number Of Phases
- 3
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Genişlik
- 45mm
- Kılıf / Paket
- PWS-A
- Forward Voltage
- 2.2V
- Terminal Pozisyonu
- UPPER
- Additional Feature
- UL RECOGNIZED
- Yayın Yılı
- 2012
- Fabrika Tedarik Süresi
- 16 Weeks
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Ambalaj
- Bulk
- Qualification Status
- Not Qualified
- Output Currentmax
- 38A
- Uzunluk
- 45mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Formu
- UNSPECIFIED
- Montaj
- Chassis Mount, Screw
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Terminal Sayısı
- 5
- Max Surge Current
- 400A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
