Volume pricing
- 1+ pcs$215.94
- 10+ pcs$208.84
- 25+ pcs$207.38
- 50+ pcs$205.94
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Power Dissipation
- 640W
- Vceon Max Vge Ic
- 3.9V @ 15V, 100A
- Typical Collector Emitter Saturation Voltage V
- 3.3
- Terminal Sayısı
- 21
- Input
- Standard
- Maximum Power Dissipation Mw
- 640
- Montaj
- Chassis Mount
- Collectoremitter Saturation Voltage
- 1.2kV
- Additional Feature
- LOW SATURATION VOLTAGE, FAST SWITCHING
- Yayın Yılı
- 2005
- Max Power Dissipation
- 640W
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- yes
- Maximum Gate Emitter Leakage Current Ua
- 0.6
- Maximum Operating Temperature C
- 125
- Polaritychannel Type
- N-CHANNEL
- Collector Emitter Voltage Vceo Max
- 1.2 kV
- Package Width
- 62
- Pcb Changed
- 14
- Igbt Type
- NPT
- Pin Sayısı
- 21
- Channel Type
- N
- Terminal Pozisyonu
- UPPER
- Package Height
- 17
- Maks. Çalışma Sıcaklığı
- + 125 C
- Collector Emitter Voltage Vceo
- 3.9V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Jesd30 Code
- R-XUFM-X21
- Mounting
- Screw
- Kılıf / Paket
- E3
- Terminal Formu
- UNSPECIFIED
- Voltage Collector Emitter Breakdown Max
- 1200V
- Maximum Collectoremitter Voltage V
- 1200
- Supplier Package
- E3
- Input Capacitance Cies Vce
- 6.5nF @ 25V
- Continuous Collector Current At25 C
- 125 A
- Case Connection
- ISOLATED
- Turn On Time
- 190 ns
- Pd Power Dissipation
- 640 W
- Eccn Us
- EAR99
