Specifications
- Terminal Sayısı
- 8
- Ambalaj
- Box
- Power Max
- 640W
- Turn On Time
- 345 ns
- Vceon Max Vge Ic
- 2.5V @ 15V, 100A
- Input
- Standard
- Transistor Element Material
- SILICON
- Montaj
- Chassis Mount, Screw
- Parça Durumu
- Obsolete
- Transistor Application
- POWER CONTROL
- Yükseklik
- 17mm
- Additional Feature
- UL RECOGNIZED
- Max Power Dissipation
- 640W
- Montaj Tipi
- Chassis Mount
- Max Collector Current
- 165A
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2007
- Uzunluk
- 122mm
- Polaritychannel Type
- N-CHANNEL
- Ntc Thermistor
- No
- Terminal Pozisyonu
- UPPER
- Turn Off Timenom Toff
- 795 ns
- Igbt Type
- NPT
- Gateemitter Voltagemax
- 20V
- Pin Sayısı
- 14
- Collectoremitter Breakdown Voltage
- 1.2kV
- Collector Emitter Voltage Vceo
- 1.2kV
- Vcesatmax
- 2.5 V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance
- 7.4nF
- Jesd30 Code
- R-XUFM-X8
- Kılıf / Paket
- E3
- Terminal Formu
- UNSPECIFIED
- Genişlik
- 62mm
- Voltage Collector Emitter Breakdown Max
- 1200V
- Configuration
- Full Bridge Inverter
- Number Of Elements
- 4
- Current Collector Cutoff Max
- 1.4mA
- Input Capacitance Cies Vce
- 7.4nF @ 25V
- Çalışma Sıcaklığı
- -40°C~125°C TJ
