Volume pricing
- 1+ pcs$176.06
- 10+ pcs$166.10
- 100+ pcs$156.70
- 500+ pcs$147.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Input
- Standard
- Yayın Yılı
- 2013
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Gateemitter Voltagemax
- 20V
- Pin Sayısı
- 11
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Turn On Time
- 110 ns
- Kılıf / Paket
- Module
- Case Connection
- ISOLATED
- Number Of Elements
- 2
- Collector Emitter Voltage Vceo
- 2.15V
- RoHS Durumu
- ROHS3 Compliant
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 11
- Fabrika Tedarik Süresi
- 16 Weeks
- Power Max
- 2100W
- Terminal Pozisyonu
- UPPER
- Vcesatmax
- 2.2 V
- Montaj Tipi
- Chassis Mount
- Current Collector Cutoff Max
- 1mA
- Configuration
- Half Bridge
- Montaj
- Chassis Mount
- Max Power Dissipation
- 2.1kW
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Collectoremitter Breakdown Voltage
- 1.2kV
- Jesd30 Code
- R-XUFM-X11
- Voltage Collector Emitter Breakdown Max
- 1200V
- Vceon Max Vge Ic
- 2.15V @ 15V, 450A
- Transistor Element Material
- SILICON
- Ntc Thermistor
- Yes
- Max Collector Current
- 650A
- Terminal Formu
- UNSPECIFIED
- Igbt Type
- PT
- Turn Off Timenom Toff
- 350 ns
- Polaritychannel Type
- N-CHANNEL
