Volume pricing
- 1+ pcs$97.41
- 10+ pcs$91.90
- 100+ pcs$86.70
- 500+ pcs$81.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 11
- Number Of Elements
- 2
- RoHS Durumu
- ROHS3 Compliant
- Collector Emitter Voltage Vceo
- 2.1V
- Kılıf / Paket
- Module
- Turn On Time
- 178 ns
- Case Connection
- ISOLATED
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Collectoremitter Saturation Voltage
- 1.8V
- Gateemitter Voltagemax
- 20V
- Kurşunsuz
- Lead Free
- Power Dissipation
- 1.5kW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Input
- Standard
- Yayın Yılı
- 2013
- Igbt Type
- PT
- Turn Off Timenom Toff
- 635 ns
- Polaritychannel Type
- N-CHANNEL
- Max Collector Current
- 465A
- Terminal Formu
- UNSPECIFIED
- Vceon Max Vge Ic
- 2.1V @ 15V, 300A
- Ntc Thermistor
- Yes
- Transistor Element Material
- SILICON
- Reference Standard
- IEC-60747
- Jesd30 Code
- R-XUFM-X11
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collectoremitter Breakdown Voltage
- 1.2kV
- Additional Feature
- UL RECOGNIZED
- Max Power Dissipation
- 1.5kW
- Pin Sayısı
- 10
- Montaj Tipi
- Chassis Mount
- Configuration
- Half Bridge
- Current Collector Cutoff Max
- 300μA
- Montaj
- Chassis Mount
- Power Max
- 1500W
- Terminal Pozisyonu
- UPPER
