Volume pricing
- 1+ pcs$64.37
- 10+ pcs$60.73
- 100+ pcs$57.29
- 500+ pcs$54.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Power Dissipation
- 560W
- Pin Sayısı
- 7
- Input Capacitance
- 5.5nF
- Yayın Yılı
- 2000
- Max Collector Current
- 135A
- Akım Değeri
- 135A
- Collectoremitter Saturation Voltage
- 2.2V
- Montaj Tipi
- Chassis Mount
- Terminal Pozisyonu
- UPPER
- Turn On Time
- 150 ns
- Turn On Delay Time
- 100 ns
- Transistor Application
- MOTOR CONTROL
- Collector Emitter Voltage Vceo
- 1.2kV
- Fabrika Tedarik Süresi
- 24 Weeks
- Voltage Collector Emitter Breakdown Max
- 1200V
- Vceon Max Vge Ic
- 2.7V @ 15V, 75A
- ECCN Kodu
- EAR99
- Case Connection
- ISOLATED
- Ambalaj
- Bulk
- Input Capacitance Cies Vce
- 5.5nF @ 25V
- Kurşunsuz Kodu
- yes
- Temel Parça No
- MII
- Collectoremitter Breakdown Voltage
- 1.2kV
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Polaritychannel Type
- N-CHANNEL
- Rise Time
- 50ns
- Kurşunsuz
- Lead Free
- Voltage Rated Dc
- 1.2kV
- Uzunluk
- 94mm
- Input
- Standard
- Transistor Element Material
- SILICON
- Ntc Thermistor
- No
- Number Of Elements
- 2
- Reach Svhc
- No SVHC
- Terminal Formu
- UNSPECIFIED
- Configuration
- Half Bridge
- Montaj
- Chassis Mount, Panel, Screw
- Additional Feature
- UL RECOGNIZED
- Turn Off Timenom Toff
- 700 ns
- Turn Off Delay Time
- 650 ns
