MID400-12E4

Specifications

Collectoremitter Breakdown Voltage

1.2kV

Turn On Delay Time

170 ns

Kılıf / Paket

Y3-Li

Montaj

Chassis Mount

Yayın Yılı

2006

Max Power Dissipation

1.7kW

Input Capacitance Cies Vce

17nF @ 25V

Turn Off Delay Time

680 ns

Max Collector Current

420A

Transistor Element Material

SILICON

Pin Sayısı

7

Vceon Max Vge Ic

2.8V @ 15V, 300A

Turn On Time

230 ns

Configuration

Single

Parça Durumu

Obsolete

Montaj Tipi

Chassis Mount

Temel Parça No

MID

Gateemitter Voltagemax

20V

Case Connection

ISOLATED

Igbt Type

NPT

Input

Standard

Ntc Thermistor

No

Terminal Pozisyonu

UPPER

Power Max

1700W

Input Capacitance

17nF

Jesd30 Code

R-XUFM-X7

Collector Emitter Voltage Vceo

2.8V

Voltage Collector Emitter Breakdown Max

1200V

RoHS Durumu

RoHS Compliant

Polaritychannel Type

N-CHANNEL

Nem Hassasiyeti (MSL)

1 (Unlimited)

Current Collector Cutoff Max

3.3mA

Terminal Sayısı

7

Kurşunsuz

Lead Free

Ambalaj

Box

Number Of Elements

1

Turn Off Timenom Toff

730 ns

Transistor Application

POWER CONTROL

Çalışma Sıcaklığı

-40°C~150°C TJ

Terminal Formu

UNSPECIFIED
