Specifications
- Uzunluk
- 94mm
- Maximum Gate Emitter Voltage V
- ±20
- Pin Sayısı
- 7
- Ntc Thermistor
- No
- Gateemitter Voltagemax
- 20V
- Parça Durumu
- Active
- Maximum Power Dissipation Mw
- 700
- Pin Sayısı
- 7
- Fabrika Tedarik Süresi
- 24 Weeks
- Max Power Dissipation
- 700W
- Typical Collector Emitter Saturation Voltage V
- 2.2
- Maximum Continuous Collector Current A
- 160
- Eu Rohs
- Compliant
- Turn On Delay Time
- 100 ns
- Yayın Yılı
- 2000
- Montaj
- Chassis Mount, Panel
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Terminal Formu
- UNSPECIFIED
- Transistor Application
- POWER CONTROL
- Mounting
- Screw
- RoHS Durumu
- ROHS3 Compliant
- Current Collector Cutoff Max
- 6mA
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Collector Emitter Voltage Vceo
- 1.2kV
- Maximum Gate Emitter Leakage Current Ua
- 0.4
- Package Width
- 34
- Jesd30 Code
- R-XUFM-X5
- Yükseklik
- 30mm
- Ppap
- No
- Terminal Pozisyonu
- UPPER
- Power Max
- 700W
- Igbt Type
- NPT
- Input
- Standard
- Maximum Collectoremitter Voltage V
- 1200
- Collectoremitter Saturation Voltage
- 1.2kV
- Case Connection
- ISOLATED
- Configuration
- Single
- Montaj Tipi
- Chassis Mount
- Temel Parça No
- MID
