Volume pricing
- 1+ pcs$138.28
- 10+ pcs$130.45
- 100+ pcs$123.07
- 500+ pcs$116.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nonrep Pk Forward Currentmax
- 15000A
- Temel Parça No
- MD*500
- Yayın Yılı
- 2000
- Montaj Tipi
- Chassis Mount
- Number Of Elements
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- GENERAL PURPOSE
- Element Configuration
- Single
- Kurşunsuz Kodu
- yes
- Diode Element Material
- SILICON
- Additional Feature
- UL RECOGNIZED
- Average Rectified Current
- 560A
- ECCN Kodu
- EAR99
- Diode Type
- Standard
- Voltage Dc Reverse Vr Max
- 1600V
- Parça Durumu
- Active
- Forward Voltage
- 1.3V
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Terminal Pozisyonu
- UPPER
- Maks. Çalışma Sıcaklığı
- 140°C
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Max Reverse Voltage Dc
- 1.6kV
- Current Reverse Leakage Vr
- 30mA @ 1600V
- Qualification Status
- Not Qualified
- Fabrika Tedarik Süresi
- 28 Weeks
- Min. Çalışma Sıcaklığı
- -40°C
- Voltage Forward Vf Max If
- 1.3V @ 1200A
- Pin Sayısı
- 2
- Ambalaj
- Bulk
- Kılıf / Paket
- Y1-CU
- Reverse Voltage
- 1.6kV
- Capacitance Vr F
- 762pF @ 400V 1MHz
- Terminal Formu
- UNSPECIFIED
- Case Connection
- ISOLATED
- Terminal Sayısı
- 2
- Number Of Phases
- 1
- Montaj
- Chassis Mount, Screw
- HTS Kodu
- 8541.10.00.80
- Peak Nonrepetitive Surge Current
- 16kA
