Volume pricing
- 1+ pcs$29.64
- 10+ pcs$27.96
- 100+ pcs$26.38
- 500+ pcs$24.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 3
- Montaj
- Chassis Mount, Panel
- Case Connection
- ISOLATED
- Voltage Forward Vf Max If
- 1.18V @ 110A
- Jesd30 Code
- R-XUFM-X3
- Terminal Formu
- UNSPECIFIED
- Max Reverse Voltage Dc
- 1.6kV
- Yükseklik
- 30mm
- Supplier Package
- TO-240AA
- Voltage Dc Reverse Vr Max
- 1600V
- Terminal Pozisyonu
- UPPER
- HTS Kodu
- 8541.10.00.80
- Automotive
- No
- Number Of Elements
- 2
- Current Reverse Leakage Vr
- 200μA @ 1600V
- Montaj Tipi
- Chassis Mount
- Ppap
- No
- Diode Configuration
- 1 Pair Series Connection
- Additional Feature
- LOW LEAKAGE CURRENT, UL RECOGNIZED
- Parça Durumu
- Active
- Forward Current
- 110A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Diode Element Material
- SILICON
- Pin Sayısı
- 7
- Pin Sayısı
- 3
- Diode Type
- Standard
- Peak Reverse Current
- 3mA
- Average Rectified Current
- 110A
- Yayın Yılı
- 2014
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Genişlik
- 20.8mm
- Maks. Çalışma Sıcaklığı
- 150°C
- Kılıf / Paket
- TO-240AA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- GENERAL PURPOSE
- Uzunluk
- 92mm
- Min. Çalışma Sıcaklığı
- -40°C
