Volume pricing
- 1+ pcs$41.49
- 10+ pcs$39.14
- 100+ pcs$36.93
- 500+ pcs$34.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 94mm
- Igbt Type
- NPT
- Vcesatmax
- 3 V
- Turn On Time
- 170 ns
- Montaj Tipi
- Chassis Mount
- Jesd30 Code
- R-XUFM-X5
- Case Connection
- ISOLATED
- Collectoremitter Breakdown Voltage
- 1.2kV
- Terminal Sayısı
- 5
- Polaritychannel Type
- N-CHANNEL
- Terminal Formu
- UNSPECIFIED
- Input
- Standard
- Transistor Application
- POWER CONTROL
- Current Collector Cutoff Max
- 4mA
- Temel Parça No
- MDI
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- Y4-M5
- Input Capacitance
- 3.3nF
- Max Power Dissipation
- 370W
- Number Of Elements
- 1
- Genişlik
- 34mm
- Yükseklik
- 30mm
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2000
- Input Capacitance Cies Vce
- 3.3nF @ 25V
- Fabrika Tedarik Süresi
- 32 Weeks
- Montaj
- Chassis Mount, Panel
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Transistor Element Material
- SILICON
- Ntc Thermistor
- No
- Voltage Collector Emitter Breakdown Max
- 1200V
- Kurşunsuz
- Lead Free
- Vceon Max Vge Ic
- 2.7V @ 15V, 50A
- Pin Sayısı
- 7
- Pin Sayısı
- 7
- Additional Feature
- UL RECOGNIZED
- Power Max
- 370W
- Turn Off Timenom Toff
- 570 ns
- Max Collector Current
- 90A
