Volume pricing
- 1+ pcs$143.26
- 10+ pcs$135.15
- 100+ pcs$127.50
- 500+ pcs$120.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Configuration
- Dual Series
- Eccn Us
- EAR99
- Parça Durumu
- Active
- Max Repetitive Reverse Voltage Vrrm
- 2.2kV
- Fabrika Tedarik Süresi
- 28 Weeks
- Terminal Formu
- UNSPECIFIED
- Package Width
- 50
- Diode Element Material
- SILICON
- ECCN Kodu
- EAR99
- Package Height
- 49
- Voltage Dc Reverse Vr Max
- 2200V
- Yükseklik
- 49mm
- Peak Reverse Current Ua
- 500
- Montaj
- Chassis Mount, Panel, Screw
- Voltage Forward Vf Max If
- 1.32V @ 600A
- Current Reverse Leakage Vr
- 30mA @ 2200V
- Terminal Sayısı
- 3
- Forward Voltage
- 1.32V
- Maks. Çalışma Sıcaklığı
- 150°C
- Ppap
- No
- Qualification Status
- Not Qualified
- Minimum Operating Temperature C
- -40
- Peak Nonrepetitive Surge Current A
- 11700
- Kurşunsuz Kodu
- yes
- Uzunluk
- 115mm
- Reach Svhc
- No SVHC
- RoHS Durumu
- ROHS3 Compliant
- Peak Reverse Current
- 30mA
- Applications
- GENERAL PURPOSE
- Min. Çalışma Sıcaklığı
- -40°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Peak Reverse Repetitive Voltage V
- 2200
- Average Rectified Current
- 310A
- Ambalaj
- Bulk
- Package Length
- 115
- Pcb Changed
- 3
- HTS Kodu
- 8541.10.00.80
- Kılıf / Paket
- Y1-CU
- Maximum Operating Temperature C
- 125
- Speed
- Standard Recovery >500ns, > 200mA (Io)
