MDD172-18N1

Specifications

Parça Durumu

Active

Kurşunsuz

Lead Free

Eccn Us

EAR99

Configuration

Dual Series

Max Repetitive Reverse Voltage Vrrm

1.8kV

Fabrika Tedarik Süresi

24 Weeks

Current Average Rectified Io

190A

Package Width

34

Package Height

30

Voltage Dc Reverse Vr Max

1800V

Peak Reverse Current Ua

1000

Montaj

Chassis Mount, Screw

Voltage Forward Vf Max If

1.15V @ 300A

Current Reverse Leakage Vr

20mA @ 1800V

Maks. Çalışma Sıcaklığı

150°C

Forward Voltage

1.15V

Ppap

No

Minimum Operating Temperature C

-40

Peak Nonrepetitive Surge Current A

7130

RoHS Durumu

ROHS3 Compliant

Peak Reverse Current

20mA

Min. Çalışma Sıcaklığı

-40°C

Nem Hassasiyeti (MSL)

1 (Unlimited)

Peak Reverse Repetitive Voltage V

1800

Ambalaj

Bulk

Average Rectified Current

190A

Package Length

94

Pcb Changed

3

Kılıf / Paket

Y4-M6

Speed

Standard Recovery >500ns, > 200mA (Io)

Maximum Operating Temperature C

125

Peak Forward Voltage V

1.22@300A

Automotive

No

Hts

8541.10.00.80

Maximum Continuous Forward Current A

190

Diode Type

Standard

Yayın Yılı

2000

Supplier Package

Y4-M6

Temel Parça No

MDD172

Max Reverse Voltage Dc

1.8kV
