Volume pricing
- 1+ pcs$124.37
- 10+ pcs$117.33
- 100+ pcs$110.69
- 500+ pcs$104.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- RoHS Durumu
- ROHS3 Compliant
- Qualification Status
- Not Qualified
- Current On State It Av Max
- 260A
- Automotive
- No
- Current Non Rep Surge5060hz Itsm
- 8500A 9180A
- Maximum Gate Trigger Voltage V
- 2
- Uzunluk
- 92mm
- Eccn Us
- EAR99
- Minimum Operating Temperature C
- -40
- Package Length
- 115
- Repetitive Peak Forward Blocking Voltage V
- 1600
- Trigger Device Type
- SCR
- Parça Durumu
- Active
- Maximum Gate Trigger Current Ma
- 150
- Configuration
- SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
- Number Of Elements
- 2
- Maximum Rate Of Rise Of Offstate Voltage Vus
- 1000
- HTS Kodu
- 8541.30.00.80
- Phase Control
- No
- Eu Rohs
- Compliant
- Çalışma Sıcaklığı
- -40°C~140°C TJ
- Rated Average Onstate Current A
- 260
- Voltageoff State
- 1.6kV
- Repetitive Peak Reverse Voltage V
- 1600
- Genişlik
- 50mm
- Ppap
- No
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Yayın Yılı
- 2013
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Chassis Mount
- Yükseklik
- 52mm
- Pin Sayısı
- 7
- Pcb Changed
- 7
- Terminal Pozisyonu
- UPPER
- Maximum Operating Temperature C
- 140
- Peak Onstate Voltage V
- 1.46@600A
- Package Width
- 50
- Montaj
- Chassis Mount, Panel
- Surge Current Rating A
- 9180
