Volume pricing
- 1+ pcs$119.85
- 10+ pcs$113.07
- 100+ pcs$106.67
- 500+ pcs$100.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Maximum Gate Trigger Current Ma
- 150
- Current On State It Av Max
- 320A
- Rated Average Onstate Current A
- 320
- Repetitive Peak Offstate Current Ma
- 1
- Yayın Yılı
- 2000
- Leakage Current Max
- 40mA
- Pcb Changed
- 5
- Mounting
- Screw
- Terminal Formu
- UNSPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Ppap
- No
- Repetitive Peak Forward Blocking Voltage V
- 1800
- Peak Onstate Voltage V
- 1.32@600A
- Çalışma Sıcaklığı
- -40°C~140°C TJ
- Onstate Currentmax
- 320000A
- Rms Current Irms
- 520A
- Repetitive Peak Offstate Voltage
- 1800V
- Maks. Çalışma Sıcaklığı
- + 140 C
- Parça Durumu
- Active
- Maximum Gate Peak Inverse Voltage V
- 10
- Pin Sayısı
- 5
- RoHS Durumu
- ROHS3 Compliant
- Vf Forward Voltage
- 1.32 V
- Technology
- Si
- Additional Feature
- UL RECOGNIZED
- Automotive
- No
- Desc Of Quickconnects
- G-GR
- Current Non Rep Surge5060hz Itsm
- 9200A 10100A
- Package Length
- 115
- Surge Current Rating A
- 10400
- Maximum Operating Temperature C
- 125
- Hts
- 8541.30.00.80
- Vr Reverse Voltage
- 1.8 kV
- Montaj Stili
- Screw Mount
- Phase Control
- No
- Tip
- Thyristor / Diode
- Desc Of Screw Terminals
- A-K-AK
- Kurşunsuz Kodu
- yes
