Specifications
- Number Of Elements
- 2
- Pin Sayısı
- 7
- Radyasyon Dayanımı
- No
- Case Connection
- ISOLATED
- Trigger Device Type
- SCR
- Number Of Scrsdiodes
- 2 SCRs
- Çalışma Sıcaklığı
- -40°C~140°C TJ
- Terminal Sayısı
- 7
- Fabrika Tedarik Süresi
- 16 Weeks
- Leakage Current Max
- 40mA
- Genişlik
- 60mm
- Parça Durumu
- Obsolete
- Pin Sayısı
- 7
- Rms Current Irms
- 450A
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Nonrepetitive Pk Onstate Cur
- 9600 A
- Montaj Tipi
- Chassis Mount
- Current On State It Av Max
- 287A
- HTS Kodu
- 8541.30.00.80
- Kurşunsuz
- Lead Free
- Reverse Voltage
- 1.6kV
- Yayın Yılı
- 2004
- Desc Of Quickconnects
- 2G-2GR
- Terminal Pozisyonu
- UPPER
- Uzunluk
- 116mm
- RoHS Durumu
- RoHS Compliant
- Hold Current
- 150mA
- Current Non Rep Surge5060hz Itsm
- 9000A 9600A
- Voltageoff State
- 1.6kV
- Repetitive Peak Offstate Voltage
- 1600V
- Yükseklik
- 30mm
- Kurşunsuz Kodu
- yes
- Temel Parça No
- MC*250
- Kılıf / Paket
- Y2-DCB
- Structure
- Series Connection - All SCRs
- Configuration
- SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- Terminal Formu
- UNSPECIFIED
- Additional Feature
- UL RECOGNIZED
