Specifications
- Insertion Forcemax
- 2.224 N
- Contact Materials
- COPPER ALLOY
- Akım Değeri
- 3A
- Body Breadth
- 0.308 inch
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 12 Weeks
- Housing Material
- Aluminium
- Uzunluk
- 1.50' 457.20mm
- Wire Size Max
- 24 AWG
- Connector Type A
- D-Sub, Plug
- Yayın Yılı
- 2006
- Contact Resistance
- 10mOhm
- Shell Finish
- NICKEL
- Lead Length
- 457.2mm
- Mating Contact Row Spacing
- 0.043 inch
- Parça Durumu
- Active
- Orientation
- Straight
- Shell Material
- ALUMINUM ALLOY
- Kablo Uzunluğu
- 457mm
- Connector Type B
- Wire Leads
- Insulation Resistance
- 5000000000Ohm
- Wire Size Min
- 32 AWG
- Renk
- Multiple, Individual
- Contact Style
- Pin
- Tip
- D-Type, Micro-D
- JESD-609 Kodu
- e4
- Min. Çalışma Sıcaklığı
- -55°C
- Seri
- MDM
- Maks. Çalışma Sıcaklığı
- 125°C
- Reliability
- COMMERCIAL
- Genişlik
- 7.82mm
- Pozisyon Sayısı
- 9
- RoHS Durumu
- Non-RoHS Compliant
- Terminal
- Crimp
- Contact Pattern
- STAGGERED
- Total Number Of Contacts
- 9
- Contact Design
- PREASSEM CONN
- Depth
- 10.57mm
- Wirecable Gauge
- 26 AWG
- 1st Connector
- Plug, Male Pins
