Volume pricing
- 1+ pcs$91.88
- 10+ pcs$86.68
- 100+ pcs$81.77
- 500+ pcs$77.14
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Durability
- 500 Cycles
- Dielectric Withstanding Voltage
- 600VAC V
- Contact Materials
- COPPER ALLOY
- Operating Temperature Max
- 125°C
- Connector Type
- D-Sub
- Uzunluk
- 1.50' 457.20mm
- Mounting Option1
- HOLE .087-.098
- Parça Durumu
- Active
- Contact Finish
- Gold
- Contact Pattern
- STAGGERED
- Shell Finish
- CADMIUM/YELLOW CHROMATE
- Nem Hassasiyeti (MSL)
- Not Applicable
- Max Current Rating
- 3A
- Insertion Forcemax
- 2.224 N
- Body Breadth
- 0.308 inch
- Contact Design
- PREASSEM CONN
- Sıra Sayısı
- 2
- Mixed Contacts
- NO
- RoHS Durumu
- Non-RoHS Compliant
- Empty Shell
- NO
- Mounting Option2
- LOCKING
- 1st Connector
- Receptacle, Male Pins
- Rated Current Signal
- 3A
- Pozisyon Sayısı
- 15
- Connector Type A
- D-Sub, Receptacle
- Option
- GENERAL PURPOSE
- Contact Style
- Pin
- Insulation Materials
- LIQUID CRYSTAL POLYMER
- Tip
- D-Type, Micro-D
- Filter Feature
- NO
- Contact Resistance
- 8mOhm
- Connector Type B
- Wire Leads
- Seri
- MDM
- Terminal
- Crimp
- Kablo Uzunluğu
- 457mm
- Withdrawl Forcemin
- .139 N
- Mating Contact Pitch
- 0.05 inch
- Ambalaj
- Bulk
- Insulation Resistance
- 5000000000Ohm
- JESD-609 Kodu
- e4
