Volume pricing
- 1+ pcs$314.40
- 10+ pcs$304.06
- 25+ pcs$301.95
- 50+ pcs$299.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- 2nd Connector
- Individual Wire Leads
- Pitch
- 2.54 mm
- Terminal Stili
- Wire Leads
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Gender
- Female
- Operating Temperature Max
- 125°C
- Rated Current Signal
- 3A
- Wirecable Type
- Coaxial
- Reference Standard
- MIL
- Total Number Of Contacts
- 31
- Mounting Option1
- HOLE .094
- Additional Feature
- STANDARD: MIL-DTL-83513
- 1st Connector
- Receptacle, Female Sockets
- Wirecable Gauge
- 26 AWG
- Contact Finish
- Gold
- Contact Plating
- Gold
- Max Current Rating
- 3A
- Option
- GENERAL PURPOSE
- Empty Shell
- NO
- Pozisyon Sayısı
- 31
- RoHS Durumu
- Non-RoHS Compliant
- Shell Plating
- Cadmium
- Contact Pattern
- STAGGERED
- Mounting Angle
- Straight
- Terminal
- Crimp
- Montaj Stili
- Panel
- Body Depth
- 0.224 inch
- Withdrawl Forcemin
- 0.139 N
- Seri
- Military, MIL-DTL-83513
- Mil Conformance
- YES
- Insulation Materials
- LIQUID CRYSTAL POLYMER
- Kurşunsuz Kodu
- no
- Filter Feature
- NO
- Mating Contact Pitch
- 0.05 inch
- Insulation Resistance
- 5000000000Ohm
- Contact Style
- RND PIN-SKT
- Tip
- DB31
- Din Conformance
- NO
- Insulation
- Insulated
- Renk
- Multiple, Individual
