Specifications
- Kablo Uzunluğu
- 457mm
- Connector Type B
- Wire Leads
- Shell Material
- Aluminum
- Parça Durumu
- Active
- Contact Style
- RND PIN-SKT
- Tip
- DB15
- Din Conformance
- NO
- Insulation
- Insulated
- Renk
- Multiple, Individual
- Filter Feature
- NO
- Number Of Contacts
- 15(POS)
- Rad Hardened
- No
- Cable Types
- Hook-up Wire
- Mating Contact Pitch
- 0.05 inch
- Current Rating Max
- 3(A)
- Insulation Resistance
- 5000000000Ohm
- Operating Temp Range
- -55C to 125C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type A
- D-Sub, Receptacle
- Wire Size Max
- 24 AWG
- Uzunluk
- 1.50' 457.20mm
- Paket
- Bulk
- Plating Thickness
- 50μin
- Body Breadth
- 0.298 inch
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Size
- 26 AWG
- Mixed Contacts
- NO
- Contact Materials
- COPPER ALLOY
- Akım Değeri
- 3 A
- Plug Receptacle
- F
- Wire Gauge
- 26 AWG
- Insertion Forcemax
- 2.78 N
- Dielectric Withstanding Voltage
- 600VAC V
- RoHS
- In Transition
- Part Aliases
- 1-1532172-9
- Fabrika Paket Adedi
- 12
- Iec Conformance
- NO
- Tradename
- MIL-DTL-83513
- Mating Contact Row Spacing
- 0.043 inch
