Volume pricing
- 1+ pcs$186.10
- 10+ pcs$175.57
- 100+ pcs$165.63
- 500+ pcs$156.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mil Conformance
- YES
- Insulation Materials
- LIQUID CRYSTAL POLYMER
- HTS Kodu
- 8536.69.40.30
- Mixed Contacts
- NO
- Empty Shell
- NO
- Pitch
- 2.54 mm
- Contact Style
- RND PIN-SKT
- Max Current Rating
- 3A
- Withdrawl Forcemin
- 0.139 N
- Wire Size Max
- 24 AWG
- Plating Thickness
- 50μin
- Rated Current Signal
- 3A
- Operating Temperature Max
- 125°C
- Additional Feature
- STANDARD: MIL-DTL-83513
- Montaj Stili
- Panel
- 1st Connector
- Plug, Male Pins
- Ürün Tipi
- D-Sub MIL Spec Connectors
- Tip
- DB31
- Shell Plating
- Cadmium
- Insertion Forcemax
- 2.78 N
- Din Conformance
- NO
- Akım Değeri
- 3 A
- Filter Feature
- NO
- Mounting Angle
- Straight
- Total Number Of Contacts
- 31
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Wirecable Gauge
- 26 AWG
- Mating Contact Pitch
- 0.05 inch
- Seri
- 83513-Style Micro D Metal Shell (MDM)
- Operating Temperature Min
- -55°C
- Kurşunsuz Kodu
- no
- Insulation Resistance
- 5000000000Ohm
- Renk
- Multiple, Individual
- Wirecable Type
- Coaxial
- Parça Durumu
- Active
- Kablo Uzunluğu
- 457mm
- Pozisyon Sayısı
- 31
- Shell Material
- Aluminum
- ECCN Kodu
- EAR99
- Contact Finish
- Gold
