Volume pricing
- 1+ pcs$107.27
- 10+ pcs$101.19
- 100+ pcs$95.47
- 500+ pcs$90.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Filter Feature
- NO
- Approvals
- CE, CSA, UL
- Mounting Angle
- Straight
- Wirecable Gauge
- 26 AWG
- Total Number Of Contacts
- 21
- Akım Değeri
- 600 A
- Terminal Stili
- Crimp
- Contact Finish Thickness
- 50.0µin (1.27µm)
- Wirecable Type
- Coaxial
- Parça Durumu
- Active
- Insulation Resistance
- 5000000000Ohm
- Seri
- M83513
- Connector Type
- D-Sub
- Withdrawl Forcemin
- .139 N
- Max Current Rating
- 3A
- Wire Size Max
- 24 AWG
- Paket
- Bag
- Mixed Contacts
- NO
- Number Of Conductors
- ONE
- Insulation Materials
- LIQUID CRYSTAL POLYMER
- 1st Connector
- Plug, Male Pins
- Ürün Tipi
- D-Sub MIL Spec Connectors
- Wire Size
- 26 AWG
- Voltage Rating
- 50 V
- Termination Method
- Crimp
- Additional Feature
- STANDARD: MIL-DTL-83513
- Operating Temperature Max
- 125°C
- Durability
- 500 Cycles
- Shell Finish
- NICKEL
- Radyasyon Dayanımı
- No
- Insulation
- Insulated
- Fabrika Tedarik Süresi
- 7 Weeks
- Size
- 15.880 L x 13.880 W x 25.750 H (403.35mm x 352.55mm x 654.05mm)
- Giriş Tipi
- Terminals
- Çıkış Tipi
- Terminals
- Temel Ürün No
- M83513/03
- Uzunluk
- 1.50 (457.20mm)
- Shell Sizes
- C
- Sıra Sayısı
- 2
- Current Rating Max
- 3(A)
