Volume pricing
- 1+ pcs$77.31
- 10+ pcs$72.94
- 100+ pcs$68.81
- 500+ pcs$64.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Rohs Code
- No
- Dielectric Withstanding Voltage
- 600VAC V
- Operating Temperaturemax
- 125 °C
- Yayın Yılı
- 2006
- 2nd Connector
- Individual Wire Leads
- Number Of Gangs
- 2
- Body Depth
- 0.223 inch
- Mating Contact Row Spacing
- 0.043 inch
- Contact Pattern
- STAGGERED
- Connector Type B
- Wire Leads
- Mounting Option1
- HOLE .094
- Wire Sizemax
- 24 AWG
- Connector Type A
- D-Sub, Plug
- Option
- GENERAL PURPOSE
- Shell Material
- METAL
- Reference Standard
- MIL
- Wire Gauge
- 26 AWG
- Body Breadth
- 0.298 inch
- Terminal
- Crimp
- Termination Type
- CRIMP
- Iec Conformance
- NO
- Part Life Cycle Code
- Active
- Pin Sayısı
- 15
- Number Of Connectors
- ONE
- Contact Materials
- COPPER ALLOY
- Tip
- DB15
- Shell Plating
- Cadmium
- Fabrika Paket Adedi
- 1
- Number Of Rows Loaded
- 2
- Insertion Forcemax
- 2.78 N
- Din Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Çalışma Sıcaklığı
- -55 to 125 °C
- Mating Contact Pitch
- 0.05 inch
- Contact Arrangement
- S15P0
- Bodyshell Style
- PLUG
- Operating Temperature Min
- -55°C
- Wire Size Min
- 26 AWG
- Wire Sizemin
- 26 AWG
