Volume pricing
- 1+ pcs$2.89
- 10+ pcs$2.73
- 100+ pcs$2.57
- 500+ pcs$2.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Pin Sayısı
- 12
- Rise Fall Time Typ
- 5ns 5ns
- Logic Voltagevil Vih
- 0.8V 2.2V
- Turn On Time
- 0.095 μs
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Interface Ic Type
- HALF BRIDGE BASED MOSFET DRIVER
- Turn Off Time
- 0.09 μs
- Yüzey Montaj
- YES
- Max Output Current
- 1.4A
- Qualification Status
- COMMERCIAL
- Kılıf / Paket
- QFN
- Min. Çalışma Sıcaklığı
- -40°C
- Genişlik
- 4mm
- Turn Off Delay Time
- 25 ns
- Max Supply Voltage
- 15V
- Driver Configuration
- Half-Bridge
- Uzunluk
- 4mm
- Current Peak Output Source Sink
- 1.4A 1.3A
- Besleme Gerilimi
- 12V
- Rise Time
- 20ns
- Power Dissipation Max
- 2.976W
- Terminal Pozisyonu
- QUAD
- Gate Type
- N-Channel MOSFET
- High Side Voltage Max Bootstrap
- 80V
- ECCN Kodu
- EAR99
- Besleme Gerilimi
- 9V~15V
- Output Peak Current Limitnom
- 1.4A
- Yayın Yılı
- 2001
- Maks. Oturma Yüksekliği
- 1mm
- Number Of Drivers
- 2
- Min Supply Voltage
- 9V
- Terminal Sayısı
- 12
- RoHS Durumu
- RoHS Compliant
- High Side Driver
- YES
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Usage Level
- Industrial grade
- Fall Time Typ
- 20 ns
