Volume pricing
- 1+ pcs$3.37
- 10+ pcs$3.18
- 100+ pcs$3.00
- 500+ pcs$2.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2001
- Output Peak Current Limitnom
- 1.4A
- Maks. Oturma Yüksekliği
- 1.75mm
- Number Of Drivers
- 2
- Output Voltage
- 75V
- High Side Voltage Max Bootstrap
- 80V
- Jesd30 Code
- R-PDSO-G8
- ECCN Kodu
- EAR99
- Gate Type
- N-Channel MOSFET
- Besleme Gerilimi
- 9V~15V
- Rise Time
- 25ns
- Besleme Gerilimi
- 12V
- Terminal Pozisyonu
- DUAL
- Power Dissipation Max
- 1.316W
- Genişlik
- 4mm
- Kılıf / Paket
- SOIC
- Min. Çalışma Sıcaklığı
- -40°C
- Current Peak Output Source Sink
- 1.4A 1.3A
- Max Supply Voltage
- 95V
- Uzunluk
- 5mm
- Driver Configuration
- Half-Bridge
- Turn Off Delay Time
- 25 ns
- Turn Off Time
- 0.09 μs
- Interface Ic Type
- HALF BRIDGE BASED MOSFET DRIVER
- Max Output Current
- 1.4A
- Yüzey Montaj
- YES
- Yükseklik
- 1.5mm
- Propagation Delay
- 82 ns
- Turn On Time
- 0.095 μs
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Max Output Voltage
- 75V
- Rise Fall Time Typ
- 5ns 5ns
- Çıkış Gerilimi
- 96.3V
- Kurşunsuz
- Lead Free
- Pin Sayısı
- 8
- Logic Voltagevil Vih
- 0.8V 2.2V
- Fonksiyon Sayısı
- 1
- Montaj
- Surface Mount
- Fabrika Tedarik Süresi
- 7 Weeks
