Volume pricing
- 1+ pcs$5.27
- 10+ pcs$4.97
- 100+ pcs$4.69
- 500+ pcs$4.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yüzey Montaj
- YES
- Max Output Current
- 3A
- Qualification Status
- Not Qualified
- Interface Ic Type
- HALF BRIDGE BASED MOSFET DRIVER
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Power Supplies
- 12V
- Pin Sayısı
- 16
- Rise Fall Time Typ
- 26ns 18ns
- Maks. Oturma Yüksekliği
- 1mm
- Number Of Drivers
- 4
- Yayın Yılı
- 2001
- Besleme Gerilimi
- 10.8V~13.2V
- Gate Type
- N-Channel MOSFET
- ECCN Kodu
- EAR99
- Jesd30 Code
- S-PQCC-N16
- High Side Voltage Max Bootstrap
- 36V
- Power Dissipation Max
- 2W
- Terminal Pozisyonu
- QUAD
- Besleme Gerilimi
- 12V
- Rise Time
- 26ns
- Max Supply Voltage
- 13.2V
- Driver Configuration
- Half-Bridge
- Current Peak Output Source Sink
- 1.25A 2A
- Kılıf / Paket
- VQFN
- Min. Çalışma Sıcaklığı
- -40°C
- Çıkış Akımı
- 3A
- Ambalaj
- Tube
- Giriş Tipi
- Non-Inverting
- Channel Type
- Synchronous
- Tepe Reflow Süresi (maks. sn)
- 40
- Pin Sayısı
- 16
- Tepe Reflow Sıcaklığı (°C)
- 260
- Operating Supply Current
- 7.1mA
- Usage Level
- Industrial grade
- Fall Time Typ
- 18 ns
- RoHS Durumu
- RoHS Compliant
- High Side Driver
- YES
